BroadAccess-1000E

ba_1000e


Overview:

BroadAccess-1000E™ is a cutting-edge FTTX MSAG designed for the delivery of residential Triple Play services and Carrier Ethernet business services. The platform offers unsurpassed flexibility with support for a complete set of voice and IP broadband services over copper and fiber. BroadAccess-1000E covers multiple functionalities including those of an MSAG, IP-DSLAM, GPON OLT and Carrier Ethernet Switch, and provides a flexible solution for FTTR, FTTB or FTTP network topology. The system supports a wide range of service interfaces, including. xDSL (ADSL2+, VDSL2, and SHDSL), GPON, Gigabit Ethernet over optical fiber and voice.

BA-1000E_Overview


Features:


Integrated Multiple Functionalities
BroadAccess-1000E integrates the functionalities of a VoIP Access Gateway, IP DSLAM, GPON OLT and Ethernet Access switch in a single platform. With a series of replaceable plug-in cards, the system enables a simple and flexible adaptation to a wide range of network applications. It supports various indoor and outdoor deployment options including environmentally hardened street cabinets.



Advanced Architecture Optimized for high bandwidth applications
With a multiple 10GigE architecture and ultra-high backplane capacity of over 360Gbps, BroadAccess-1000E provides an optimal solution for broadband applications such as HD IP-TV and Carrier Ethernet business services. The  system offers high bandwidth service interfaces (ADSL2+, VDSL2, GPON, and Ethernet over fiber) and an Nx10GigE network interface, whilst implementing advanced features of QoS, Security and Multicast.



Integrated Resilient Ethernet Ring Transport
The system incorporates an integrated resilient 10Gigabit Ethernet ring transmission, providing an ideal solution for the delivery of high capacity triple play and carrier Ethernet services. In addition to its high speed the Ethernet transport ensures an enhanced resiliency with a sub 50 millisecond protection switchover time.



High Capacity & Density
BroadAccess-1000E offers an industry leading capacity of 864-1152 ports per shelf, enabling service providers to efficiently serve a large service area from a compact shelf.



Modularity
BroadAccess-1000E’s modular architecture provides operators with the ability to adapt the system to the specific requirements of each service area, in terms of line capacity and types of services. The system supports any mix of services - from POTS to xDSL and IP over fiber.



Carrier-Class
BroadAccess-1000E ensures a continuous and reliable service with a high level of immunity to failures. The system is enhanced with redundant common cards, comprehensive testability, and advanced OAM and QoS features.


Technical Data:



Services: ADSL2+
VDSL2
SHDSL/SHDSL.bis
Ethernet
GPON
POTS
ISDN
IP Network Interfaces: NxGigE, Nx10GigE
IP/Ethernet: Ethernet switching 802.1d
VLAN tagging 802.1q
VLAN stacking 802.1ad
VLAN priority 802.1p
IGMP snooping / proxy
Protocols: PPPoE, IPoE, PPPoA, IPoA
Voice Network Interface:
NGN (H.248, SIP), PSTN (V5.2)
Transmission: Resilient optical ring, NxGigE, 10GigE
Operating Temperature: Indoor and outdoor environment
Management: SNMP based
Client Server Architecture
XML/SOA Northbound interface




EMS:

BroadAccess-1000E is managed by ClearAccess, a smart, comprehensive Element Management System (EMS) that offers efficient, cost-effective control of thousands of BroadAccess-1000E systems. The system’s advanced functionalities and effortless operation significantly reduce operational costs and improve service quality, thus assuring smooth network performance and maximizing the network’s potential.
