The BroadAccess-100 Mini IP DSLAM offers a range of solutions for FTTN (Fiber to the Node) configurations. Its environmentally hardened structure and compactness make it ideal for outdoor deployments in confined spaces such as cabinets or buildings outside the Central Office.




High Bandwidth Support
Using standards-compliant ADSL2+, the system delivers 24 Mbit/s downstream and over 1 Mbit/s upstream over copper, providing an optimal solution for IPTV.


Ideal for Triple Play
The system is well furnished for IPTV, with IP Multicast, advanced traffic management, security features and flexible VLAN mapping.


Compact & Dense
BroadAccess-100 is designed as a 1U “pizza box” unit, including 48/96 ports with integrated POTS splitters.


Environmentally Hardened
With its extra-durable protection suitable for any climate, the system is ideal for installation in street cabinets.


The system offers several options to suit service providers' needs, including electrical and optical IP Gigabit Ethernet uplinks, and a cascading option


Standards Compatibility
BroadAccess-100 is designed in compliance with the DSL Forum’s TR-101.

Technical Data:


Services: 96 or 48 x ADSL2+ (including POTS splitters)
Dimensions (H x W x D):
4.44 x 48.3 x 25.2 cm (1 RU)
IP Network Interface: 1-2 GigE
IP/Ethernet: Ethernet switching 802.1d
VLAN tagging 802.1q
VLAN stacking 802.1ad
VLAN priority 802.1p
IGMP snooping / proxy
Protocols: PPPoE, IPoE, PPPoA, IpoA
Operating Temperature: Indoor and outdoor environment
Management: SNMP based
Client Server Architecture
XML/SOA Northbound interface



BroadAccess-100 is managed by ClearAccess, a smart, integrated management system that offers efficient, cost-effective control of a vast network of BroadAccess-100 systems. The system’s advanced functionalities and effortless operation significantly reduce operational costs and improve service quality, thus assuring smooth network performance and maximizing the network’s potential.
