Overview:
As part of a complete FTTx solution, Teledata offers a comprehensive set of GPON ONTs (Optical Network Terminals) and MDUs (Multi Dwelling Units) which offer a wide range of functionalities and service interfaces. The ONTs support advanced capabilities to provide Triple-Play and business applications.
Features:
- Broad line of indoor and outdoor models for Residential, Business, MDU, and cellular backhaul applications
- Triple-Play capabilities – Ethernet, POTS and IP-TV or RF-video
- Robust support for both IPTV and RF video deployments
- IGMP support for IPTV
- Wire speed packet processing with full support for 802.1Q VLAN and 802.1p Traffic prioritization
- Leading VoIP capabilities with extensive list of certified interoperable Softswitches and gateways
- Standard compliance ITU-T G.984 GPON
Technical Data:
| Standard compliance: | GPON standards ITU-T G.984 |
| User interfaces: | ONT/ONU: - 1-4 Fast Ethernet / Gigabit Ethernet - 1-2 FXS - WiFi - USB - RF Video MDU: - 1-24 Fast Ethernet - 1-24 FXS - VDSL2 |
| IP/Ethernet Features: | 802.1Q VLAN tagging 802.1p QoS 802.1ad VLAN stacking IGMP V2/V3 Residential Gateway (routing, NAT, DHCP, PPPoE, Firewall) |
| VoIP: | SIP or H.248 control G.729 and G.711 CODECs T.38 fax relay and legacy G.711 pass-through |
| WiFi | 802.11n , 802.11a/b/g |
| ONT Management: |
GPON OMCI ONT remote management |
| Operating Environment: |
Indoor ONT’s Operating temperature: 0°C to +40°C Outdoor ONT’s Operating temperature: -40°C to +60°C Storage temperature: -20°C to 70°C Humidity: 20 to 95% non-condensing |
